Page 99
SECTION 4 - PLATFORM
3121248
1930ES/2030ES/2630ES/2646ES/3246ES
99
FIGURE 4-8. DRIVE/STEER CONTROLLER ASSEMBLY(USA BUILT MACHINES AND BELGIUM BUILT
MACHINES) (SN 0200172402 through 0200198014, SN 1200015409 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
See Note
1
DRIVE/STEER CONTROLLER ASSEMBLY (Note: Use p/n
1001134438 as replacement (was p/n 1600402)).
A
1
70001250
1
Boot, Panel
2
70001252
1
Gasket, Mounting
2
70001251
1
Bezel, Mounting
3
70003650
1
Handle Repair Kit (Includes handle gasket, item #4 push button
and item #4 lever installed in front handle half, back handle half,
top actuator, boot and hardware.)
3
70000084
1
Cap, Rubber
3
70000082
1
Microswitch
3
7027766
1
Ring, Retaining
3
7027365
1
Actuator, Handle
3
70001253
1
Gasket, Handle
3
70000683
4
Washer, Neoprene
3
70000685
2
Spacer, Plastic
3
70000686
2
Screw (Top)
3
70000684
2
Screw (Bottom)
4
7027367
1
Switch, Push button
4
7027765
1
Lever, Enable
