SECTION 9 - RECOMMENDED SERVICE PARTS STOCK
182
1930ES/2030ES/2630ES/2646ES/3246ES
3121248
FIGURE 9-2. MODEL ES VARIABLE PARTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Note
Ref
Note: The following list will service one machine (built to
current production per date on the front cover) with emergency
repair parts which can be installed in the field. Parts from the
list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact
your JLG dealer or the JLG Industries Parts Department.
Ref
VARIABLE PARTS
1600346
1
Drive Module (Frame)
2915064
1
Relay (UL Spec)
3740150
1
Relay (Non-UL Spec)
1001114933
1
Tilt Module
4360469
1
Switch, Key (ANSI/ANSI Export Spec)
4360470
1
Switch, Key (CE/AUstralian Spec)
3080007
1
Magnet, Latch (Machines with Platform Gate Entry)
1001101076
1
Snap Latch Repair Kit (Machines with Platform Chain Entry)
1001091965
1
Control Module (Platform)
1001109088
1
Switch, Limit
1001109475
1
Breaker, Circuit 16 Amp (CE Spec Machines with Platform Electrical
Outlet)
1001109482
1
Breaker, Circuit 30mA (CE Spec Machines with Platform Electrical
Outlet)
4360613
1
Limit Switch (Machines with Optional Brake Disconnect)
4360336
1
Switch, Toggle (ANSI and CSA Spec Machines with Optional
Battery Charger/Inverter Combo)
3990010
2
Diode 6 Amp (ANSI and CSA Spec Machines with Optional Battery
Charger/Inverter Combo)
