SECTION 6 - HYDRAULIC
3121248
1930ES/2030ES/2630ES/2646ES/3246ES
113
FIGURE 6-1. HYDRAULIC DIAGRAM
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
HYDRAULIC COMPONENTS
0272371
Ref
Steer Hydraulics (1930ES)
G
0273227
Ref
Steer Hydraulics (2030ES/2630ES)
D
0274546
Ref
Steer Hydraulics (2646ES/3246ES)
B
2792599
Ref
Hydraulic Schematic
D
5
Ref
Hose Options:
5
Ref
Hose 1930ES
5
2753882
2
Hose USA Built Machines (SN 0200152825 through
0200161588)
5
2753882
2
Hose Belgium Built Machines (SN 1200008481 through
1200011442)
5
2755056
2
Hose USA Built Machines (SN 0200161589 through
0200198014)
5
2755056
2
Hose Belgium Built Machines (SN 1200011443 to Present)
5
Ref
Hose 2030ES/2630ES
5
2753882
2
Hose USA Built Machines (SN 0200152825 through
0200161588)
5
2753882
2
Hose Belgium Built Machines (SN 1200008481 through
1200011442)
5
2755061
2
Hose USA Built Machines (SN 0200161589 through
0200198014)
5
2755061
2
Hose Belgium Built Machines (SN 1200011443 to Present)
5
2753883
2
Hose 2646ES/3246ES
13
2110404
2
Fitting, Straight
Ref
STEER CYLINDER ASSEMBLY
1684237
Ref
Steer Cylinder Assembly 1930ES/2030ES/2630ES
D
1684456
Ref
Steer Cylinder Assembly 2646ES/3246ES
A
109
2110404
2
Fitting, Straight Adapter
