SECTION 1 - FRAME
3121248
1930ES/2030ES/2630ES/2646ES/3246ES
25
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
21
Ref
Clamp, Cable Options:
Ref
Note: Due to service updates, cable clamps may be any of
the various designs listed below. Visual identification will be
required.
21
Ref
All except UL Spec
21A
3574714
1
Clamp (Available on All Models)
21B
1001091492
1
Clamp (Available on 1930ES)
21C
1001094301
2
Clamp (Available on 2030ES/2630ES/2646ES/3246ES)
21
Ref
UL Spec
21D
1320162
1
Clamp (Available on All Models)
21E
3574714
1
Clamp (Available on 1930ES)
21F
1001091492
1
Clamp (Available on 1930ES)
21G
1001094301
2
Clamp (Available on 2030ES/2630ES/2646ES/3246ES)
22
1321283
1
Clamp, Hose (2646ES/3246ES Only - USA Built Machines) (SN
0200158825 through 0200170585)
22
1321283
1
Clamp, Hose (2646ES/3246ES Only - Belgium Built Machines)
(SN 1200008481 through 1200015159)
23
4340751
AR
Mount, Cable Clamp (UL Spec Only)
24
4811900
AR
Flatwasher M8
25
4811700
AR
Flatwasher M6
30
4923602
1
Harness, Field Wire Connection (Not Shown - See ELECTRICAL
SECTION for Breakdown) (USA Built Machines) (SN
0200156117 through 0200198014)
30
4923602
1
Harness, Field Wire Connection (Not Shown - See ELECTRICAL
SECTION for Breakdown) (Belgium Built Machines) (SN
1200008263 to Present)
31
1001094124
AR
Block, Spacer (1930ES With Service Upgrade Only)
Ref
ALARM INSTALLATIONS
0272810
Ref
ANSI and ANSI Export and UL Specs (USA and Belgium Built
Machines)
F
0273966
Ref
ANSI Export and Japanese Specs (USA and Belgium Built
Machines)
C
0273443
Ref
Australian Specs without Overload (USA and Belgium Built
Machines)
D
0272811
Ref
Australian and CE Specs with Overload (USA and Belgium
Built Machines)
F
0272722
Ref
Descent Alarm
A
0272913
Ref
Motion Alarm
A
102
0140043
1
Alarm
105
4191706
2
Screw M6 x 12mm
