SECTION 4 - PLATFORM
3121248 1930ES/2030ES/2630ES/2646ES/3246ES 95
ITEM PART NUMBER QTY DESCRIPTION REV
SECTION for Breakdown)
27 1703819 1 Decal - Directional Arrow
28 Ref Screw M3.5 x 12mm Options:
28 4191306 6 Screw USA Built Machines (SN 0200152825 through
0200163755)
28 4191306 6 Screw Belgium Built Machines (SN 1200008481 through
1200011997)
28 1001091396 6 Screw USA Built Machines (SN 0200163756 through
0200198014)
28 1001091396 6 Screw Belgium Built Machines (SN 1200011998 to Present)
50 Ref Kit Options:
50A 1001091967 1 Decal Kit for USA Built Machines (Includes Items 6, 16 & 28)
(SN 02000152825 through 0200163755) A
50A 1001091967 1 Decal Kit for Belgium Built Machines (Includes Items 6, 16 &
28) (SN 1200008481 through 1200011997) A
Ref Note: Two Item 6's are included in the kit - 1 for All Specs
Except CE and 1 for CE Specs. Use decal required for
applicable spec. Dispose of the decal not used.
Ref Note: If Housing has been replaced with Kit 1001091393 or
Kit 1001091965, use Decal Kit p/n 1001091968
50B 1001091968 1 Decal Kit for USA Built Machines (Includes Items 6, 16 & 28)
(SN 0200163756 through 0200198014) A
50B 1001091968 1 Decal Kit for Belgium Built Machines (Includes Items 6, 16 &
28) (SN 1200011998 to Present) A
Ref Note: Two Item 6's are included in the kit - 1 for All Specs
Except CE and 1 for CE Specs. Use decal required for
applicable spec. Dispose of the decal not used.
50C 1001091393 1 Decal and Housing Kit (Includes Items 6, 12, 16 & 28) C
Ref Note: Two Item 6's are included in the kit - 1 for All Specs
Except CE and 1 for CE Specs. Use decal required for
applicable spec. Dispose of the decal not used.
50D 1001091965 1 Decal, Housing and PC Board Kit (Includes Items 2, 6, 12, 14,
16, 19, 23, 24 & 28) C
Ref Note: Two Item 6's are included in the kit - 1 for All Specs
Except CE and 1 for CE Specs. Use decal required for
applicable spec. Dispose of the decal not used.
0272878 Ref Anti-vandelism Package Installation (Not Shown) A
1671131 1 Cover, Lockable Platform Console Box
1001118216 Ref PLATFORM BOX COVER INSTALLATION (was p/n 0273841) A-C
101 Ref Kit, Platform Box Shield Options:
101 1001118215 Original Equipment (was p/n 0273841)
101 1001118215 Service Replacement
101A 0760808 4 Bolt M8 x 16mm
101B 1380159 4 Clip, Cover Mounting
101C Item 101 1 Cover, Platform Box
101D 3290805 4 Locknut M8
0274386 Ref PLATFORM BOX HANGER INSTALLATION (OPTIONAL) B
201 3290405 2 Locknut M4
202 3575794 1 Plate, Bracket
203 3900338 2 Screw M4 x 20mm
204 4811400 4 Flatwasher M4
