SECTION 1 - FRAME
28
1930ES/2030ES/2630ES/2646ES/3246ES
3121248
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
18
3577030
1
Plate, Attach (Left) Belgium Built Machines (SN 1200009514
through 1200022846)
18
1001109233
1
Plate, Attach (Left) USA Built Machines (SN 2000195918
through 0200198014)
18
1001109233
1
Plate, Attach (Left) Belgium Built Machines (SN 1200022847 to
Present)
19
3290605
4
Locknut M6
20
4811700
4
Flatwasher M6
21
0700614
4
Screw M6 x 30mm
22
Ref
Switch, Limit Options:
22
1001109345
2
Switch, Limit USA Built Machines (was p/n 4360633) (SN
0200152825 through 2000195917)
22
1001109345
2
Switch, Limit Belgium Built Machines (was p/n 4360633) (SN
12000008481 through 1200022846)
22
1001109088
2
Switch, Limit USA Built Machines (SN 2000195918 through
0200198014)
22
1001109088
2
Switch, Limit Belgium Built Machines (SN 1200022847 to
Present)
