SECTION 1 - FRAME
3121248 1930ES/2030ES/2630ES/2646ES/3246ES 9
FIGURE 1-1. STEERING, DRIVE AND REAR AXLE INSTALLATIONS (USA BUILT MACHINES AND
BELGIUM BUILT MACHINES) (SN 0200152825 through 0200170584, SN 1200008481 through
1200015158)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref STEERING INSTALLATION
0272371 Ref Steering Installation (1930ES) G
0273227 Ref Steering Installation (2030ES/2630ES) D
0274546 Ref Steering Installation (2646ES/3246ES) B
1 0440259 2 Bearing, Flanged
2 Ref Bolt M10 Options:
2 0701016 4 40mm Length
2 0701020 4 60mm Length
3 1380153 4 E-Clip
4 Ref Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown):
4 1684237 1 Steer Cylinder Assembly (1930ES/2030ES/2630ES)
4 1684456 1 Steer Cylinder Assembly (2646ES/3246ES)
7 3423037 4 Pin, Clevis
8 4812000 4 Flatwasher M10
9 4846757 2 Lug, Steer
10 0100011 AR Compound, Locking
13 2110404 2 Fitting, Straight
Ref DRIVE INSTALLATION
0275185 Ref Drive Installation (1930ES) USA Built Machines (SN
0200152825 through 0200161931) D
0275185 Ref Drive Installation (1930ES) Belgium Built Machines (SN
1200008481 through 1200011006) D
0275445 Ref Drive Installation (1930ES) USA Built Machines (SN
0200161932 through 0200170585) A
0275445 Ref Drive Installation (1930ES) Belgium Built Machines (SN
1200011007 through 1200015159) A
0275188 Ref Drive Installation (1930ES) (UL SPEC) USA Built Machines (SN
0200152825 through 0200161931) E
0275188 Ref Drive Installation (1930ES) (UL SPEC) Belgium Built Machines
(SN 1200008481 through 1200011006) E
0275445 Ref Drive Installation (1930ES) (UL SPEC) USA Built Machines (SN
0200161932 through 0200170585) A
0275445 Ref Drive Installation (1930ES) (UL SPEC) Belgium Built Machines
(SN 1200011007 through 1200015159) A
0275186 Ref Drive Installation (2030ES/2630ES) C
0275189 Ref Drive Installation (2030ES/2630ES) (UL SPEC) D
0275187 Ref Drive Installation (2646ES/3246ES) C
0275190 Ref Drive Installation (2646ES/3246ES) (UL SPEC) D
102 0630580 20 Bolt, Wheel
105 2780266 2 Hub Assembly (See Items 201-208 for Breakdown)
106 Ref Wheel Drive Assembly Options (See WHEEL DRIVE
ASSEMBLY for Breakdown):
106 Ref Wheel Drive Assembly (1930ES)
106 2915236 2 Wheel Drive Assembly (1930ES) USA Built Machines (was
p/n 3160306) (SN 0200152825 through 0200161931)
106 2915236 2 Wheel Drive Assembly (1930ES) Belgium Built Machines (was
p/n 3160306) (SN 1200008481 through 1200011006)
106 1001100974 2 Wheel Drive Assembly (1930ES) USA Built Machines (was
p/n 3160337) (SN 0200161932 through 0200170585)
