SECTION 1 - FRAME
3121248
1930ES/2030ES/2630ES/2646ES/3246ES
39
FIGURE 1-8. BATTERY CHARGER WITH INVERTER ASSEMBLY AND INSTALLATION (OPTIONAL ON
ANSI AND CSA SPEC MACHINES)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
BATTERY CHARGER ASSEMBLY
0275103
Ref
Battery Charger Assembly (1930ES)
D
0275104
Ref
Battery Charger Assembly (2030ES/2630ES)
C
0275105
Ref
Battery Charger Assembly (2646ES/3246ES)
C
1
0100011
AR
Compound, Locking
2
1001093839
1
Charger/Inverter Assembly (was p/n 0400237)
3
Ref
Hardware Options:
3
0760812
4
Bolt M8 x 25mm
3
0760814
4
Bolt M8 x 30mm
3
3290805
4
Nut M8
4
0902780
1
Bracket, Mounting (Remote Switch)
5
Ref
Bracket, Mounting (Charger/Inverter)
5
0903444
1
Bracket, Mounting (1930ES)
5
0903319
1
Bracket, Mounting (2030ES/2630ES/2646ES/3246ES)
6
1320043
1
Clamp
7
1705052
1
Decal - On/Off
8
2820239
1
Insulation, Charger Mounting
9
Ref
Screw M6 Options:
9
4191706
AR
Screw 12mm Length
9
4191707
AR
Screw 16mm Length
10
4811700
2
Flatwasher M6
11
4740562
4
Washer, Special
18
1706749
1
Decal - Inverter (Not Shown - Located on Frame Near Inverter)
19
Ref
Decal - Hazardous Voltage Options (Not Shown - Located on
Platform Near AC Box):
19
1706765
1
Decal English Language
19
1001136847
1
Decal Spanish Language
