SECTION 1 - FRAME
3121248
1930ES/2030ES/2630ES/2646ES/3246ES
13
FIGURE 1-2. STEERING, DRIVE AND REAR AXLE INSTALLATIONS (USA BUILT MACHINES AND
BELGIUM BUILT MACHINES) (SN 0200170585 through 0200198014, SN 1200015159 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
STEERING INSTALLATION
0272371
Ref
Steering Installation (1930ES)
G
0273227
Ref
Steering Installation (2030ES/2630ES)
D
0274546
Ref
Steering Installation (2646ES/3246ES)
B
1
0440259
2
Bearing, Flanged
2
Ref
Bolt M10 Options:
2
0701016
4
Bolt 40mm Length
2
0701020
4
Bolt 60mm Length
3
1380153
4
E-Clip
4
Ref
Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown):
4
1684237
1
Steer Cylinder Assembly (1930ES/2030ES/2630ES)
4
1684456
1
Steer Cylinder Assembly (2646ES/3246ES)
7
3423037
4
Pin, Clevis
8
4812000
4
Flatwasher M10
9
4846757
2
Lug, Steer
10
0100011
AR
Compound, Locking
13
2110404
2
Fitting, Straight
Ref
DRIVE INSTALLATION
1001092739
Ref
Drive Installation (1930ES)
D
1001092740
Ref
Drive Installation (2030ES/2630ES)
D
1001092741
Ref
Drive Installation (2646ES/3246ES)
D
101
0630580
20
Bolt, Wheel
105
2780266
2
Hub Assembly (See Items 201-208 for Breakdown)
108
3760463
2
Ring, Retaining
111
4740524
2
Thrustwasher M60
112
4740564
2
Washer, Spindle Retaining
117
Ref
Wheel Drive Assembly Options (See WHEEL DRIVE
ASSEMBLY for Breakdown):
117
1001092737
2
Wheel Drive Assembly (1930ES)
117
1001092738
2
Wheel Drive Assembly (2030ES/2630ES/2646ES/3246ES)
117
1001092738
2
Wheel Drive Assembly (2646ES/3246ES)
2780266
Ref
HUB ASSEMBLY
B
Ref
Note: Qtys shown for 1 Assembly. Two Assemblies required
per machine.
201
7012524
1
Cap, Dust
202
7010641
1
Nut, Slotted
203
7010642
1
Pin, Cotter 2in x 3/16in
204
7019697
1
Washer
205
7026185
1
Bearing, Cone - Outer
206
Not Available
1
Hub (Purchase Complete Hub p/n 2780266)
207
7026183
1
Bearing, Cone - Inner
208
7026184
1
Seal
Ref
FRAME WELDMENT
301
Ref
Bushing Options:
301
0440264
2
Bushing (1930ES)
301
0440265
2
Bushing (2030ES/2630ES/2646ES/3246ES)
302
Ref
Kingpin Rework Instruction Options (Provides rework procedure
for damaged kingpins):
302
3128601
AR
Kingpin Rework Instruction (1930ES/2030ES/2630ES)
