SECTION 7 - ELECTRICAL
144
1930ES/2030ES/2630ES/2646ES/3246ES
3121248
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
505C
Not Available
1
AC Input Harness (Internal Part of Inverter)
505D
Not Available
1
Receptacle, Female - 4 Position (Conxall T9016)
505E
Not Available
1
Remote Control Harness (Internal Part of Inverter)
505F
Not Available
1
Plug, Male - 8 Position (Conxall 7281-8PG-300)
505G
1001091479
1
AC Input Harness (was p/n 4923389)
A-D
505H
4460138
1
Plug, Male
505J
Not Available
1
Plug, Male - 4 Position (Conxall T9017)
505K
4923390
1
AC Output Harness
D
505L
4460779
1
Receptacle, Female
505M
Not Available
1
Plug, Male - 4 Position (Conxall T9015)
505N
4923391
1
Data Interface Harness
D
505P
Not Available
1
Plug, Male - 8 Position (Conxall 6280-8SG-318)
505R
4460899
1
Receptacle, Female - 6 Position
505R
4460464
4
Pin, Male
505R
4460466
2
Plug, Seal
505R
3990010
1
Diode 6A/600V
505S
4360336
1
Switch, Toggle
505T
4460424
2
Receptacle, Female - 2 Position
505T
4460267
2
Pin, Male
505U
4923392
1
Cable, Battery + to Inverter +
A
505V
4923393
1
Cable, Battery - to Inverter -
A
506
1001093556
1
MDI Harness (USA Built Machines Only) (SN 0200168420
through 0200198014)
B
506
1001093556
1
MDI Harness (Belgium Built Machines Only) (SN 1200014906 to
Present)
B
506A
4460321
1
Plug, Male
506A
4460226
4
Socket, Female
506B
4460868
1
Plug, Male - 6 Position
506B
4460877
4
Terminal
506B
1001094105
1
Boot
Ref
Tools for Service
601
7002821
1
Crimper, Wire (Not Shown)
602
7002823
1
Extractor, Pin - Universal (Not Shown)
603
4460467
AR
Extractor, Pin #16 Gauge (Not Shown)
604
4460510
AR
Extractor, Pin #12 Gauge (Not Shown)
605
7002828
1
Stripper, Wire (Not Shown)
606
2901443
1
Analyzer Kit (Not Shown)
606A
1600244
1
Analyzer
606B
1060633
1
Cable, Analyzer
606C
4460321
2
Plug, Male - 4 Position
606C
4460226
8
Socket, Female
607
1001137005
1
Software Cables Kit (Not Shown)
