Page 130
SECTION 7 - ELECTRICAL
130
1930ES/2030ES/2630ES/2646ES/3246ES
3121248
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
505R
4460466
2
Plug, Seal
505R
3990010
1
Diode 6A/600V
505S
4360336
1
Switch, Toggle
505T
4460424
2
Receptacle, Female - 2 Position
505T
4460267
2
Pin, Male
505U
4923392
1
Cable, Battery + to Inverter +
A
505V
4923393
1
Cable, Battery - to Inverter -
A
506
1001093556
1
MDI Harness (USA Built Machines Only) (SN 0200168420
through 0200198014)
B
506
1001093556
1
MDI Harness (Belgium Built Machines Only) (SN 1200014906 to
Present)
B
506A
4460321
1
Plug, Male
506A
4460226
4
Socket, Female
506B
4460868
1
Plug, Male - 6 Position
506B
4460877
4
Terminal
506B
1001094105
1
Boot
Ref
TOOLS FOR SERVICE
601
7002821
1
Crimper, Wire (Not Shown)
602
7002823
1
Extractor, Pin - Universal (Not Shown)
603
4460467
AR
Extractor, Pin #16 Gauge (Not Shown)
604
4460510
AR
Extractor, Pin #12 Gauge (Not Shown)
605
7002828
1
Stripper, Wire (Not Shown)
606
2901443
1
Analyzer Kit (Not Shown)
606A
1600244
1
Analyzer
606B
1060633
1
Cable, Analyzer
606C
4460321
2
Plug, Male - 4 Position
606C
4460226
8
Socket, Female
607
1001137005
1
Software Cables Kit (Not Shown)
