JLG 3246ES Parts Manual - Manual (Page 71)

SECTION 3 - SCISSOR ARMS
3121248 1930ES/2030ES/2630ES/2646ES/3246ES 71
ITEM PART NUMBER QTY DESCRIPTION REV
53 4812000 4 Flatwasher M10
54 4071094 AR Shim, Spacer
55 3423170 1 Pin
56 3291007 1 Locknut M10
2902475 1 Scissor Arm Kit - 2646ES/3246ES (Includes Items 1-10, 17, 18,
36, 49, 51 & 52) L
Ref SCISSOR ARMS INSTALLATIONS - 2646ES/3246ES
0274879 Ref Scissor Arms Installations (2646ES) with Standard Hydraulic
Oil D
0275695 Ref Scissor Arms Installations (2646ES) with Biodegradeable
Hydraulic Oil C
0274881 Ref Scissor Arms Installations (3246ES) with Standard Hydraulic
Oil D
0275696 Ref Scissor Arms Installations (3246ES) with Biodegradeable
Hydraulic Oil C
102 0701022 2 Bolt M10 x 70mm
104 3200454 1 Mount, Switch
105 3291005 2 Locknut M10
107 3340957 2 Pad, Slide
108 3423255 1 Pin, Sensor
111 4191706 3 Screw M6 x 12mm
114 1001092354 1 Switch, Rotary Angle Sensor (was p/n 4360526)
115 1061034 1 Cable, Manual Descent (Not Shown)
115 7020218 1 T-Handle (with 1/4in-20 Threads)
115 70001878 1 T-Handle (with 5mm Threads)
116 3321402 1 Nut, Jam 1/4in-28NF (Not Shown)
117 4160078 1 Spring, Compression (Not Shown)
118 4420070 AR Tape, Anti-Skid (3 Pcs 41mm X 279mm Each)
119 4420080 AR Tape, Anti-Skid (1 Pc 60mm X 279mm) (Not Shown - Located on
Bottom Step - Part of Frame)
