2-50 3121106
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
209 7019994 Sensor, EGR 1
210 2420187 Dipstick 1
4564281 Tube, Dipstick 1
211 2720341 Horn, Rubber Air 1
212 7022142 Switch, Oil Pressure (Black) 1
213 Use 7021868 Filter, Oil (was p/n 7022147) 1
214 7016662 Coupling, Pump 1
215 7019993 Pressure Regulator & Filter Assembly 1
216 Not Used
217 7022158 Connector 3
218 7022159 Connector 2
219 7022160 Connector 1
220 7022161 Tube, Supply A/R
221 7022162 Clamp 2
222 3124114 EFI System Diagnostic Service Manual (Not Shown) 1
223 7023637 Switch, Oil Shutdown (White) 1
224 7022178 Sensor, Crank Shaft 1
225 7020120 Housing, Bell 1
226 70002567 Tensioner, Timing Belt 1
227 Gasket Options: (Not Shown) A/R
Use 7025124 Kit, Gasket Upper (was p/n 7022148) 1
7022149 Kit, Gasket Lower 1
7025134 Gasket, Water Outlet 1
7022143 Gasket, Exhaust (Manifold to Cylinder Head) 1
7022144 Gasket, Upper Manifold Throttle
228 7022150 Belt, Timing 1
229 7022151 Cap, Oil Filler 1
230 7022152 Injector, Fuel 4
231 7022153 Water Pump Assembly 1
7022154 Gasket, Water Pump 1
232 7022155 Sensor, Water Temperature 1
233 7022156 Thermostat, Assy 1
234 7019930 Coil, Ignition
7022157 Wire Set, Spark Plug (Not Shown) 1
Use 7019932 Spark Plug (Not Shown) (was p/n 7012595) 4
235 7019925 PCV Valve (Not Shown) 1
236 7023613 Relay 3
237 7022179 Sensor, Camshaft (Not Shown) 1
238 7019976 Flywheel Assembly (Not Shown) 1
7022180 Gear, Ring (Not Shown) 1
239 7022164 Switch, High Coolant Temperature (Not Shown) 1
240 7023644 Hose, Water Pump (By-Pass) (Not Shown) 1
241 7027402 Belt, Drive (was p/n 7019979) 1
70002567 Tensioner, Belt 1
242 70002307 Gasket, Exhaust (Manifold to Pipe) 1
FIGURE 2-14. FORD LRG-425EFI DUAL FUEL ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
