SECTION 9 RECOMMENDED SERVICE PARTS STOCK
MODELS 100SX/110SX/110SXJ/120SXJ
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10
10-20
20 OR MORE
STANDARD PARTS
7012944
Coil (Figures 1-1 & 2-3)
1
1
1
7021401
Coil (Figures 1-1 & 2-3)
1
1
1
7012943
Coil (Figures 1-1, 1-2, 1-8 & 2-3)
1
1
1
4360362
Switch, Level Sensor (Figure 2-2)
1
1
1
7017451
Coil (Figure 2-3)
1
1
1
0610084
Board, Circuit - Engine Relay (Figure 2-10)
1
1
1
0610080
Board, Circuit - Select (Figure 2-10)
1
1
1
0610130
Board, Circuit - Load Radius (Figure 2-10)
1
1
1
0610100
Board, Circuit - Overload (Figure 2-10)
1
1
1
3740070
Relay - SPDT (Figure 2-10)
1
1
1
3740016
Relay - 3PDT (Figure 2-10)
1
1
1
3740122
Relay - 2PDT (Figure 2-10)
1
1
1
3740049
Relay - 5PDT (Figures 2-10, 2-13 & 4-5)
1
1
1
4360216
Breaker, Circuit - 30 Amp (Figure 2-10)
1
1
1
4360232
Breaker, Circuit - 15 Amp (Figure 2-10)
1
1
1
4360469
Switch, Key (Figure 2-10)
1
1
1
2860030
Key, Replacement (Figure 2-10)
1
1
1
4360212
Breaker, Circuit - 3 Amp (Figure 2-10)
1
1
1
4360314
Switch, Toggle (Figures 2-10, 2-11 & 4-5)
1
1
1
4360475
Switch, Mushroom (Figures 2-10, 2-11 & 4-5)
1
1
1
3740112
Relay (Figure 2-10)
1
1
1
4360476
Contact, Switch Block (Figures 2-10 & 4-5)
1
1
1
4360328
Switch, Toggle (Figure 2-10)
1
1
1
4360069
Breaker, Circuit - 10 Amp (Figure 2-10)
1
1
1
4360340
Switch, Potentiometer (Figure 2-11)
1
1
1
4360345
Switch, Toggle (Figures 2-11 & 4-5)
1
1
1
3990001
Diode - 3 Amp (Figure 2-11)
1
1
1
2120136
Element, Charge Pump Filter (Figure 2-12)
4
8
12
3740059
Relay (Figure 2-12)
1
1
1
3740067
Relay (Figure 2-12)
1
1
1
7008829
Board, Circuit (Figure 2-12)
1
1
1
7008828
Cable, Throttle (Figure 2-12)
1
1
1
7004214
Element, Air Filter (Figure 2-12)
1 Dozen
1 Dozen
1 Dozen
7000649
Filter, Engine Fuel (Deutz) (Figure 2-12)
1
1
1
7014503
Filter, Engine Oil (Deutz) (Figure 2-12)
1 case
1 case
1 case
4360336
Switch, Toggle (Figures 2-13 & 4-5)
1
1
1
3990010
Diode - 6 Amp (Figures 2-13 & 7-5)
1
1
1
4360294
Breaker, Circuit - 30 Amp (Figure 2-13)
1
1
1
1660233
Coupling (Deutz) (Figure 2-14)
1
1
1
1340046
Breather, Hydraulic (Figure 2-17)
1
1
1
