3121106 3-23
S
E
C
T
I
O
N
3
B
O
O
M
SECTION 3 BOOM
FIGURE 3-6. BOOM WIPERS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0253303 BOOM WIPERS INSTALLATION Ref. 2
1 3200344 Mount, Boom Wiper (Base/Top) 1
2 3200346 Mount, Boom, Wiper (Inner Mid/Top) 2
3 3200348 Mount, Boom, Wiper (Outer Mid/Top) 1
4 3200345 Mount, Boom, Wiper (Base/Side) 2
5 3200347 Mount, Boom Wiper (Inner Mid/Side) 2
6 3200349 Mount, Boom Wiper (Outer Mid/Side) 2
7 0540074 Blade, Boom Wiper (Base/Top) 1
8 0540089 Blade, Boom Wiper (Inner Mid/Top) 2
9 0540078 Blade, Boom Wiper (Outer Mid/Top) 1
10 0540075 Blade, Boom Wiper (Base/Side) 2
11 0540077 Blade, Boom Wiper (Inner Mid/Side) 2
12 0540079 Blade, Boom Wiper (Outer Mid/Side) 2
13 2660067 Holder, Brush (Base/Top) 1
14 2660085 Holder, Brush (Inner Mid/Top) 2
15 2660071 Holder, Brush (Outer Mid/Top) 1
16 2660068 Holder, Brush (Base/Side) 2
17 2660070 Holder, Brush (Inner Mid/Side) 2
18 2660072 Holder, Brush (Outer Mid/Side) 2
19 3820001 Rivet, Pop 30
20 1670491 Cover Weldment 1
21 0641404 Bolt 1/4" -20NC x 1/2" 4
22 4761400 Lockwasher 4
23 4711600 Flatwasher 4
