2-48 3121106
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
115 3620040 Radiator 1
7019656 Radiator Cap 1
116 0641608 Bolt 3/8”-16NC x 1” 19
117 4751600 Flatwasher 3/8” 64
118 3311605 Nut, Centerlock 3/8” - 16NC 32
119 0080214 Fan Spacer Adapter 1
120 2060025 Fan Suction 1
121 0700819 Bolt, Metric 8mm x 1.25 x 55mm 4
122 4831900 Lockwasher, Metric 8mm 4
123 0100011 Loctite #242 (Not Shown) A/R
124 1703162 Decal, Fan Blade 1
125 1580011 Tank, Coolant Recovery 1
126 2720058 Hose, Coolant Recovery 12ft/3.7m
127 1320022 Clamp 9
128 2720435 Lower Radiator Hose (Not Shown) 1
129 2720436 Upper Radiator Hose 1
130 1320012 Clamp, Radiator Hose 4
131 0641616 Bolt 3/8” -16NC x 2” 16
132 0642018 Bolt 5/8” - 11NC x 2 1/4” 2
133 4752000 Flatwasher 5/8” 4
134 3312005 Locknut, 5/8” x 11NC 2
135 3572978 Plate, Engine Mount (Front) 1
136 3570133 Plate, Engine Mount (Rear) 1
137 3200362 Rubber Mount 4
138 0641828 Bolt 1/2” - 13NC x 3 1/2” 4
139 3311805 Nut 1/2” x 13NC 4
140 4740274 Flatwasher, Snubbing 4
141 1600298 Controller, ECM 1
142 4568158 Standoff, 1/4” - 2” ECM 4
143 0641424 Bolt 1/4” -20NC x 3” 4
144 3600208 Pump, Auxiliary 1
145 0641612 Bolt 3/8” - 16NC x 1 1/2” 2
146 4791600 Starwasher 3/8” 3
147 2720472 Hose, Fuel 1
148 2220805 Fitting, 90° 1/8” NPT x 5/16 Hose Barb 1
149 4641022 Valve Needle 1
150 4568119 Tube, Fuel 1
151 0100062 Retaining Compound (Not Shown) 4
152 4568259 Tube, Fuel 1
153 2200221 Plug, Pipe (Not Shown) 1
154 0641416 Bolt 1/4” - 20 x 2” 3
155 4567879 Tube, Exhaust 1
156 0701012 Bolt, Metric 10mm x 1.5 x 25mm 4
157 4832000 Lockwasher, Metric 10mm 4
158 4568258 Pipe, Exhaust 1
159 1320019 Clamp, Exhaust 1
160 3740080 Relay, Bosch 1
161 3530425 Plate, Mounting 1
162 3740067 Relay, Auxiliary Power 1
FIGURE 2-14. FORD LRG-425EFI DUAL FUEL ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
