3121106 3-15
S
E
C
T
I
O
N
3
B
O
O
M
SECTION 3 BOOM
FIGURE 3-3. JIB BOOM INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0258414 JIB BOOM INSTALLATION OPTIONS: Ref. 1
1 0801156 Boom, Jib 1
2 3422727 Pin (Left Side Attach) 1
3 3323403 Nut, Slotted 1 1/2" x 12NF 1
4 3422679 Pin (Right Side Attach) 1
5 3420592 Hairpin 1
6 3451012 Pin, Cotter 5/16" x 3" 1
7 0901835 Bracket, Limit Switch 1
8 4360277 Switch, Limit 1
9 4360307 Head, Switch 1
10 4460049 Connector, Strain Relief 1
11 0721016 Screw, Machine #10-24NC x 2" 2
12 3311005 Locknut #10-24NC 2
13 4751000 Flatwasher #10 2
14 0641615 Bolt 3/8"-16NC x 1 7/8" 2
15 3311605 Locknut 6
16 1320184 Clamp, Hose and Cable 2
17 3535978 Plate 2
18 1670635 Cover, Hose and Cable 1
19 4300076 Stud (Welded on Part) 4
20 3311602 Nut, Jam 3/8"-16NC 4
21 4751600 Flatwasher 3/8" 4
22 3532793 Plate, Hose Cover 1
23 4300032 Stud (Welded on Part) 4
24 3311405 Locknut 1/4"-20NC 4
25 4751400 Flatwasher 1/4" 4
26 4060803 Trim, Flexible 10 in.
27 2880814 Keystock (Welded on Part) 2
28 0962181 Bushing, Garmax 2
29 1060016 Cable 16/3 (S/N 60361 to Present) 50’
