JLG 120-SXJ ANSI Parts Manual User Manual
Page 231
3121106
8-3
SECTION 8
DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-1. DECALS INSTALLATION - ANSI
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
STANDARD DECAL INSTALLATIONS
0259933
Decals - JLG
Ref.
1
0259931
Model 100SX/110SX
Ref.
8
0259932
Models 110SXJ/120SXJ
Ref.
4
1
1703797
Decal - Danger/Warning (Platform)
1
2
1703798
Decal - Danger/Warning (Ground Control)
1
3
1703805
Decal - Danger/Electrocution
3
4
1703804
Decal - Warning Crushing
5
5
1704533
Decal - Legend (Platform)
1
6
1704585
Decal - Legend (Ground Control)
1
7
Decal - Model Designation Options:
2
1704599
Model 100SX
1704591
Model 110SX
1704590
Model 110SXJ
1704592
Model 120SXJ
8
3572327
Plate, Decal Mount
1
9
1702774
Decal - JLG Lift (3.5in)
1
10
1702773
Decal - JLG (5in)
2
11
1702868
Decal - No Hands
2
12
1704277
Decal - Attach Lanyard Here
4
13
Decal - Capacity (Platform) Options:
1
1704096
100SX/110SX
1704096
110SXJ/120SXJ (Prior to S/N 54101)
1701645
110SXJ/120SXJ (S/N 54101 to Present)
14
Decal - Capacity (Ground Control) Options:
1
1704104
100SX/110SX
1704104
110SXJ/120SXJ (Prior to S/N 54101)
1702688
110SXJ/120SXJ (S/N 54101 to Present)
15
3251813
Decal - USA
1
16
1701502
Decal - High Oil Level
1
17
1701503
Decal - Low Oil Level
1
18
1701504
Decal - Hydraulic Oil
2
19
1702153
Decal - Inspection
1
20
Not Available
Decal - Bar Code
1
21
1700584
Decal - Patent
1
22
Not Available
Nameplate - Serial Number
1
23
1701509
Decal - Manual
1
24
1702300
Decal - Tie Down
6
25
1701500
Decal - Lift
4
26
1701501
Decal - Arrow
4
27
3251243
Nameplate - 120V-60Hz
1
28
0860520
Box, Manual Storage
1
29
1060279
Cable, Lanyard
1
30
0641408
Bolt 1/4”-20NC x 1”
1
31
1703953
Decal - Warning Crushing
2
32
1702862
Decal - JLG Lift (12in)
2
