SECTION 4 PLATFORMS
79 0100020 Sealant (Not Shown) (S/N 56133 to Present) A/R
2910864
Decal Kit - Console Box (Includes Items 7-11 and
301)
2
CONSOLE BOX ASSEMBLIES: Ref.
Use 0861640 Production (was p/n 0861353) Ref. 1/A
0861640 Post Production Alternative Ref.
101 Not Available Lid, Cast 1
102 Not Available Bottom, Box 1
103 2600211 Hinge (Used on p/n 0861353) 2
104 3900224 Capscrew, Socket Head Countersunk 6mm x 16mm
(Used on p/n 0861353) 8
105 3931672 Capscrew, Socket Head 3/8”-16NC x 4 1/2” 1
106 0100011 Loctite #242 (Not Shown) (Used on p/n 0861353) A/R
107 3311601 Nut 3/8”-16NC 1
CONSOLE BOX OPTIONS Ref.
201 4WS Switch Option Components A/R
4360331 Switch, Toggle 1
3790012 O-Ring 1
202 Dual Switch Option Components A/R
0271414 Dual Fuel Switch Installation 1
4360336 Switch, Toggle 1
3790012 O-Ring 1
203 Lights Switch Option Components A/R
4360336 Switch, Toggle 1
3790012 O-Ring 1
204 Articulating Jib Switch Option Components A/R
4360314 Switch, Toggle 1
3790012 O-Ring 1
LIGHT PANEL DECAL INSTALLATIONS Ref.
0270046 100SX/110SX - ANSI Ref. 1
0259885 100SX/110SX - ANSI Export Ref. 1
0259887 110SXJ/120SXJ Ref. 1
301 Decal - Light Panel Display Options: 1
1704477 100SX/110SX - ANSI
1704476 100SX/110SX - ANSI Export
1704475 110SXJ/120SXJ
302 2920129 Bulb, Light A/R
4922352 ELECTRICAL COMPONENTS INSTALLATIONS: Ref. 5/G
401 4460503 Connector - 31 Position 1
402 4460613 Connector - 21 Position 1
403 4120035 Socket, Light 10
FIGURE 4-5. PLATFORM CONSOLE ASSEMBLY (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
