3121106 3-21
S
E
C
T
I
O
N
3
B
O
O
M
SECTION 3 BOOM
FIGURE 3-5. BOOM LENGTH INDICATOR AND LIMIT SWITCHES INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0250119 BOOM LENGTH/INDICATOR INSTALLATION Ref. 2
1 0239485
Boom Length Indicator Assembly
(See Item 101-104 for Breakdown)
1
2 4300032 Stud (Welded on Part) 4
3 4761400 Lockwasher 1/4" 4
4 3311401 Nut 1/4"-20NC 4
0239485 BOOM LENGTH INDICATOR SUBASSEMBLY Ref. D
101 0860575
Indicator Box Assembly
(See Items 201-206 for Breakdown)
1
102 4360153 Pendulum 1
103 3910408 Screw #4NC x 1/2" 4
104 4770400 Starwasher #4 4
105 Not Used
106 4460428 Strain Relief 1
0860575 INDICATOR BOX ASSEMBLY Ref. E
201 7000637 Potentiometer 1
70002305 Holder, Potentiometer 1
202 7000638 Switch 1
203 7000639 Spring, Reel 1
204 7012526 Spring, Extension 1
205 7000647 Cable 1
206 3730024 Resistor - 100 Ohms 1
0270234 BOOM LIMIT SWITCHES INSTALLATION Ref. 3
301 4360277 Switch, Limit 1
302 4360236 Switch, Head 1
303 4360278 Switch, Roller Arm 1
304 Connector, Strain Relief Options: 1
4460052 Prior to S/N 56617
4460049 S/N 56617 to Present
305 3900168 Screw #10-24NC x 1 1/2" 2
306 4920140 Wire, Safety 1
307 Not Used
308 Not Used
309 4761400 Lockwasher 1/4" 4
310 3311401 Nut 1/4"-20NC 4
311 1670579 Cover 1
312 Not Used
313 1320040 Clamp, Cable 2
314 Not Used
315 1670836 Cover, Boom 1
