3-8 3121106
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
107 Cable, Electrical - 16/30 1
4922406 100SX
4922404 110SX/110SXJ - With Inverted Power Track
4922405 120SXJ
108 Cable, Electrical 16/4 Options: 50 ft./15m
1060079
110SXJ/110SXJ - With Inverted Power Track
(Prior to S/N 60361 Only)
Not Required 100SX/110SX/110SX - With Inverted Power Track
109 to 110 Not Used
111 1180254 Carrier Tube Weldment (Right Side) 1
112 Carrier (Right Side) Options: 1
1180236
Carrier Without Covers (Right Side) - 100SX/
110SX/110SXJ/120SXJ
1
7006153 Repair Section - 1 Foot A/R
7006133 Feet, Mounting (1 Pair) 2
7006138 Pin Kit A/R
Use 1001119697
Carrier Without Covers (Right Side) - 110SX/
110SXJ - With Inverted Power Track (was p/n
1180289)
1
Gemco Replacement Parts:
7016503 Repair Section - 1 Foot A/R
7006133 Feet, Mounting (1 Pair) 2
7006138 Pin Kit A/R
Gortrac Replacement Parts:
70003145 Repair Section - 1 Foot A/R
70003146 Feet, Mounting (1 Pair) 2
113 Cover, Boom End Options: 1
4843107 100SX/110SX
4843087 110SXJ
4843107 110SX/110SXJ - With Inverted Power Track
4843087 120SXJ
114 3532793 Plate, Hose Cover 1
115 4060685 Shield, Hose and Cable (Right Side) 2
116 4060684 Shield, Hose and Cable (Right Side) 1
117 Support, Hydraulic Line Options: 4
1320279 100SX/110SX/110SXJ/120SXJ
4340413 110SX - With Inverted Power Track
1320279 110SXJ - With Inverted Power Track
118 4300098 Stud (Welded on Part) 8
119 3311401 Nut 1/4"-20NC 16
120 4751400 Flatwasher 1/4" 17
121 4761400 Lockwasher 1/4" 16
122 4300032 Stud (Welded on Part) 6
123 3840858 Rod, Tube Retainer 1
124 4562516 Tube 1
125 4340453 Support, Bracket 1
126 Not Used
127 4761500 Lockwasher 5/16" 3
128 0641510 Bolt 5/16"-18NC x 1 1/4" 3
129 3311501 Nut 5/16"-18NC 3
FIGURE 3-1. BOOM ASSEMBLY COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
