JLG 120-SXJ ANSI Parts Manual - Manual (Page 100)

2-70 3121106
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
207 3520022 Plug, Magnetic 1
208 1340045 Basket, Strainer 1
209 3960371 Gasket 1
210 3300205 Nut, Retainer 5/16"-18NC 3
211 2180606 Nipple, Pipe 1
212 2120104 Filter 1
213 3311401 Nut 1/4"-20NC 14
214 4761400 Lockwasher 1/4" 14
215 0100020 Sealant, Thread (Not Shown) A/R
216 4751400 Flatwasher 1/4" 14
FUEL CAP ASSEMBLY OPTIONS: Ref.
0257365 STANDARD Ref. 1
0257366 “RED” - PROTECTOSEAL Ref. 2
0258626 “BLUE” - PROTECTOSEAL Ref. 1
301 Cap, Fill Options: 1
1120314 Cap, Fill - Standard
1120367 Cap, Fill - “Red” Protectoseal
1120512 Cap, Fill - “Blue” Protectoseal
FIGURE 2-20. TANKS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
