3121106 6-3
S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
S
SECTION 6 HYDRAULICS
FIGURE 6-1. HYDRAULIC DIAGRAM - DRIVE (4WD / DEUTZ / FORD ENGINE)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
2792433 HYDRAULIC DIAGRAM - DRIVE (DEUTZ) Ref. 4
2792529 HYDRAULIC DIAGRAM - DRIVE (FORD) Ref. 2
1 1320033 Clamp 2
2 2210014 Fitting, 90° Barbed 1
3 2220365 Fitting, 45° 4
4 2220366 Fitting, 90° 13
5 2220371 Fitting, Straight 1
6 2220373 Fitting, Straight 8
7 2220374 Fitting, Straight 2
8 2221064 Fitting, Tee 1
9 2220377 Fitting, Straight 5
10 2220386 Fitting, 90° 2
11 2220415 Fitting, Straight 19
12 2220451 Fitting, Straight 5
13 2220466 Fitting, 90° 7
14 2220500 Fitting, 45° 5
15 Fitting Options:
2220501 45° (Deutz Engine) 1
2220646 90° (Ford Engine) 2
16 2220628 Fitting, 90° 1
17 2220811 Fitting, Reducer 5
18 2220909 Fitting, Orfice (.015) 1
19 2221041 Fitting, Tee 1
20 2221052 Fitting, Tee 1
21 2752593 Hose 1
22 2752473 Hose 1
23 2753410 Hose 1
24 2752322 Hose 1
25 2752630 Hose 1
26 2753483 Hose 4
27 2753429 Hose 4
28 2753432 Hose 4
29 Hose Options: 1
2753316 Prior to S/N 55566
2753495 S/N 55566 to Present
30 2753434 Hose 4
31 2753423 Hose 4
32 2753435 Hose 1
33 Hose Options: 1
2753437 Prior to S/N 55566 (Deutz Engine)
2753509 S/N 55566 to Present (Deutz Engine)
2752461 (Ford) Engine)
34 Hose Options: 1
2752494 Prior to S/N 55566
2753510 S/N 55566 to Present
35 2752494 Hose 1
