3121106 3-9
S
E
C
T
I
O
N
3
B
O
O
M
SECTION 3 BOOM
130 4751500 Flatwasher 5/16" 6
131 Not Used
132 4740349 Washer, Special 1
133 Not Used
134 3536001 Plate, Ramp (Left Side) 1
135 3421571 Pin, Attach 2
136 Not Used
137 Not Used
138 Not Used
139 3430408 Pin, Clevis 1/4" x 1" 1
140 3450203 Pin, Cotter 1/16" x 3/4" 1
141 to 148 Not Used
149 Cable 16/3 Options: 50ft/15m
Not Required 100SX/110SX/110SX - With Inverted Power Track
1060016 110SXJ/120SXJ
1060016 110SXJ - With Inverted Power Track
150 to 151 Not Used
152 Fitting, Grease Options: 2
Not Required 110SX/110SX - With Inverted Power Track
2160001 100SX/110SX/110SXJ/120SXJ
153 3340494 Pad, Wear (Inner Mid Front Bottom) 2
154 4070600 Shim 1/8"/3.2mm A/R
155 4070601 Shim 1/16"/1.6mm A/R
156 Not Required
157 Not Used
158 0741608 Screw, Countersunk 3/8"-16NC x 1" 1
159 Not Used
160 Not Used
161 0641407 Bolt 1/4" - 20 NC x 7/8" 2
162 1670836
Cover (Not Shown)
Located on Bottom of Boom Sections)
8
163 0641611 Bolt 3/8"-16NC x 1 3/8" 2
— — — — — — — — — —
0100011 Loctite #242 A/R
RADIUS LIMIT TAPE INSTALLATIONS Ref.
0239878/1282060 100SX - 50’ Reach Ref. 3/F
0252764/1282060 110SX - 55’ Reach Ref. 3/F
0239878/1282060 110SX - 60’ Reach Ref. 3/F
0251100/1282060 110SXJ - 55’ & 60’ Reach Ref. 4/F
0252764/1282060 120SXJ - 55’ & 60’ Reach Ref. 3/F
201 Tape Options: 6 in./15.3cm
4420016
Tape - Yellow
(100SX - 50’ Reach/110SX - 60’ Reach)
4420018 Tape - Blue (110SXJ - 55’ & 60’ Reach)
Not Required 110SX - 55’ Reach
Not Required 120SX - 55’ & 60’ Reach
202 4420017 Tape - Red 6 in./15.3cm
203 4420015 Tape - White 6 in./15.3cm
FIGURE 3-1. BOOM ASSEMBLY COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
