Concentrator plus/Vacufuge® plus — Operating manual
2 Product description
2 Product description
2.1 Main illustration
The fold-out page depicts front and rear views of the complete system (see Fig. A) and the basic
device (see Fig. B).
2.2 Features
Concentrator plus and Vacufuge plus are designed for the evaporation of liquid or wet samples in
micro test tubes, round-bottom tubes, Falcon tubes, flat-bottom tubes and different plates.
You can insert the following tubes and plates:
• 1.5 and 2.0 mL micro test tubes in a rotor with 70 places.
• 0.5 mL micro test tubes in a rotor with 72 places.
• 15 mL Falcon tubes in a rotor with 8 places.
• 50 mL Falcon tubes in a rotor with 6 places.
• MTP and PCR plates in a swing-bucket rotor.
A complete list can be found in the following chapter (see Rotors on p. 11)
The device is available as a complete system with integrated diaphragm vacuum pump or as a
basic device without vacuum pump. The basic device can be connected to an external vacuum
system.
Key, practical functions of Concentrator plus or Vacufuge plus have been optimized:
• 3 temperature levels can be set (30, 45, 60 °C). Alternatively, evacuation is carried out
without thermoregulation.
• The evaporation of liquids can be carried out optimized in 3 functions. In addition to pure
evacuation, aqueous and/or alcoholic solutions can be concentrated extra fast with 2 special
functions.
• You can also operate the device as a pure desiccator.
• You can connect a solvent trap to the device behind the pump.
Due to the space-saving design, the device can be situated directly on the workstation. With its
clearly laid-out control panel with only a few, clearly marked elements and a display that is easy
to read, the device is a pleasant and reliable companion in your daily work.
1 Pump outlet (complete system)
Outlet of the integrated diaphragm
vacuum pump, e.g., for tubing connection
to the emission condenser.
2 Lid made from PMMA
3 Sealing ring 4 Grip recess
5 Emergency release 6 Pump housing (complete system)
7 Name plate 8 Mains connection
9 Fuse holder 10 Mains power switch
11 Operating controls and device display 12 Emission condenser (complete
system)
13 Pump connection (basic device)
For tubing connection to external vacuum
pump.
14 Mains connection for external vacuum
pump (basic device)
