Concentrator plus/Vacufuge® plus — Operating manual
20
4.2.3 Complete system: removing the transport protection screw
1. Carefully place the device and transport protection pad on its side.
Abb. 1: Transport protection screws on the underside of the Concentrator plus/Vacufuge plus complete system
Fig. 1: Transport protection screws on the underside of the Concentrator plus/Vacufuge plus
complete system
2. Lightly move the rear transport protection pad on the underside of the device towards the
back until the rear transport protection screw (1) is visible.
3. Unscrew and remove the two transport protection screws.
4. Push the rear transport protection pad back to its original position.
5. Place the device and transport protection pad upright again.
4.2.4 Place the device upright
1. Remove the front and rear transport protection pads.
2. Remove the plastic coverings from the device and lid.
3. Place the device upright in a well-ventilated area protected from direct sunlight to prevent it
from continuing to heat up.
4.2.5 Check the delivery
1. Check that delivery is complete (see Delivery package on p. 10).
2. Check all parts for any transport damage. Please contact your distributor if there is any
damage.
1 Rear transport protection screw 2 Front transport protection screw
2
1
WARNING!
Operating an incorrectly installed device poses a risk of injury.
The device is not ready for operation after it has been placed upright. Additional components are
missing.
 Read the following chapter before operating the device (see Installing the instrument on
p. 21).
Hint!
Proceed in reverse order when packing the Concentrator plus/Vacufuge plus.
