Concentrator plus/Vacufuge® plus — Operating manual
2.4.1 Special notes on the individual rotors
Rotor F-45-72-8 and rotor F-45-48-11
• You can place two of these rotors on top of each other in any arrangement by using a spacer
(order no. int.: 5301 316.005 / North America: 022822101) and centrifuge them at the same
time.
• For this combination, lower upper limits apply to the maximum payload: bottom rotor: 2/3 of
the max. payload, top rotor 1/3 of the max. payload.
• Rotor F-45-72-8 and F-45-48-11: Included with the accessories are rotor feet which can be
screwed into the corresponding bores on the rotor. Their purpose is to prevent the samples
from being pushed out of the bores when the rotor is put down on the work bench. The rotors
can be centrifuged with the rotor feet. The screws must be checked monthly and re-tightened,
if required.
Rotor F-45-24-12
• Tube length  75 mm: max. capacity 24 tubes.
• Tube length > 75 mm: max. capacity 12 tubes.
Rotor A-2-VC
• Tubes, PCR strips and plates without frame can only be used with a suitable work plate
(see Adapters on p. 44).
• Max. loading height: 27 mm.
Rotor F-35-6-30
• The recommended maximum filling volume for 50 mL Falcon tubes is 44 mL. If the tubes are
filled up to the top, the rotational movement may cause the samples to overflow.
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
