IKA  -WERKE C 7000 Ver. 07 09.07
3DJH
7HFKQLFDO 'DWD
7HFKQLFDO GDWD IRU & &DORULPHWHU
Operating voltage 100 V-120 V / 220 V-240 V
Operating frequency 60 / 50 Hz
Power consumption 100 W
Fuses for 230 V supply:
for 115 V supply:
2 x 1.0 AT
1 x 630 mAT
1 x 250 mAT
2 x 2.0 AT
1 x 1.3 AT
1 x 500 mAT
Degree of protection to DIN 40 050 IP 21
Protection class 1 (with protective earth)
Over-voltage category 2
Contamination level II
Ambient temperature 18°C ... 30°C (constant)
Max. relative humidity of environment 80 %
Use above sea level max. altitude 2000 m
Dimensions (B x D x H) unit closed:
unit open:
310 x 490 x 395 mm
310 x 490 x 460 mm
Weight 25 kg
Measuring range 30 000 J
Interfaces 2 x serial (RS 232) for PC
and balance
1 x parallel for printer
1 x connection for C 7002
cooler
7HFKQLFDO GDWD IRU & &RROHU
Operating voltage 100 V-120 V / 220 V-240 V
Operating frequency 60 / 50 Hz
Power consumption 160 W
Fuses for 230 V supply:
for 115 V supply:
2 x 1.25 AT
2 x 2.5 AT
Degree of protection to DIN 40 050 IP 21
Protection class 1 (with protective earth)
Over-voltage category 2
Contamination level II
Ambient temperature 18°C ... 30°C (constant)
Max. relative humidity of environment 80 %
Use above sea level max. altitude 2000 m
Dimensions (B x D x H) 360 x 290 x 245 mm
Weight 12.3 kg
Interface 1 x connection for C 7002
calorimeter
Cooling power (only Peltier elements) 80 W (with cooling water
supply at 2 l/min)
Water inlet pressure max. 9 bar
