SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We
recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally
available at automotive dealerships and parts stores.
ADVANCE ADAPTERS INC. P/N: 303009A
P.O. Box 247, 4320 Aerotech Center Way New Item: (05/04)
Paso Robles, CA 93447 PAGE 1 OF 5
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 12-12-12
KIT CONSISTS OF:
No. Qty Part No. Description
ATLAS TRANSFER CASE CABLE SHIFTER
SOLD WITHOUT AN ATLAS
1. 1 302051 TWIN STICK BASE MOUNT
2. 1 302060 TWIN STICK SHIFT BOOT
3. 1 302061 FRONT SHIFT KNOB
4. 1 302062 REAR SHIFT KNOB
5. 1 302063 BOOT RING
6. 1 302080 1/2"-13 x 7" ALL THREAD
7. 1 303120 1/2"-13 SERRATED LOCK NUT
8. 3 303121 1/2"-13 JAM NUT
9. 1 303301 SHIFTER BODY
10. 1 303303 BARREL RETAINER PLATE
11. 2 303304 SHIFTER HANDLE
12. 2 303305 CABLE BARREL
13. 2 303306 SHIFT RAIL ADAPTER
14. 1 303307 EXTENSION TUBE BRACKET
(THIS BRACKET HAS 3 CABLE SUPPORT HOLES, USE THE TWO THAT ARE IN LINE WITH THE MOUNTING STUD HOLE)
15. 1 303308 EXTENSION TUBE 4.85" LONG
16. 2 303309 SHIFTER CABLE - 48" LONG
17. 1 303310A PIVOT SHOULDER BOLT- 5/16" x 3"
18. 4 303312 HANDLE PIVOT BUSHINGS
19. 2 303313 1/4" FEMALE HEIM JOINT
20. 3 340615 1/4"-20 x 5/8" BUTTON HEAD CAP SCREW
21. 1 722523 1/4" FLAT WASHER
22. 4 722546 #10 x 1" SELF TAPPING SCREWS
23. 1 723141 5/16"-18 LOCKNUT
24. 3 723731 3/8"-16 x 1" SOCKET HEAD CAP SCREW
25. 2 340617 1/4-28 X 1" SHCS (HANDLE TO HEIM BOLTS)
The shifter body, handles, and pivot
bolt were updated 11-10-11. These items
retained the same part numbers, but will
not fit as replacement parts for older
shifter units. If a replacement handle or
body is needed then you will need the
new style components. The old pivot
bolt can be obtained from McMaster
Carr.
