Left side view of machine 3-8, Serial number location 3-8, Specifications – Snorkel ATB50 CE User Manual
Page 34
page 3 - 8
ATB 42/50 – 0161987EE
3. Specifications
Upper riser boom
Lower riser boom
Jib boom
Serial
number
Front
steering wheels
Rear
drive wheels
Turntable
Ground
controls
Rear lifting
tie down lugs
Chassis
Platform
u
Left Side View Of Machine
Front
steering wheels
Rear
drive wheels
Chassis
Serial number stamped
on top of chassis tube
Serial number stamped
on left side of chassis
u
Serial Number Location
