Nomenclature and Serial Numbers
ATB 42/50 – 0161987EE
page 3 - 7
3. Specifications
Rear
drive wheels
Front
steering wheels
Main boom
Serial
number
Turntable
Chassis
Platform controls
Platform
Front lifting
tie down lugs
u
Right Side View Of Machine
Tip boom
Base boom
ATB 50 Main boom = Tip boom + Base boom
u
Booms Identification
