Level Sensor
The level sensor, located behind the ground
control box, detects how far out of level the
turntable is.
If the turntable gets over 5° out of level and
booms are raised, the level sensor activates the
tilt alarm.
u
Platform Swinging Gate
The optional platform swinging gate is designed
to automatically close after you enter or leave the
platform. It helps prevent people from falling off
the platform.
u
Platform Work Lights
The optional platform work lights are located on
top the platform guardrail. For the lights to work,
the Battery switch must be ON and the following
switches, on the ground control box, must be set
as indicated:
Platform/Ground Selector . . . . . . . PLATFORM
Emergency Stop. . . . . . . . . . . . Pulled Out (ON)
Master Key Switch . . . . . . . . . . . . . . . . . . . . ON
The toggle switch on the back of a light turns it on.
A
CAUTION
Incandescent lights draw three amperes (35
watts) each. Halogen lights draw four amperes
(50 watts) each.
If you work with the lights turned on and the
engine turned off, the battery can discharge to
the point it will not start the engine nor run the
Emergency Power hydraulic pump.
If you cannot leave the engine running while
the lights are on, start and run the engine at
least 15 minutes in each hour to keep the
battery charged.
ATB 42/50 – 0161987EE page 2 - 7
2. Safety Devices
