Overall Dimensions - ATB 50

ATB 42/50 – 0161987EE

page 3 - 5

3. Specifications

7'-6"

(2.3m)

6'-0"

(1.8m)

Center of gravity
in stowed position

3'-8"

(114cm)

2'-10"

(86cm)

6'-11"

(2.1m)

4'-0"

(1.2m)

4'-9"

(1.4m)

7'-6"

(2.3m)

8'-0"

(2.4m)

21'-0"

(6.4m)

6'-10"

(2.1m)

8'-11"

(2.7m)

14.4"

(36.5cm)

15.9"

(40cm)

2'-10"

(86cm)

3'-11"

(1.1m)
