Be certain the tow vehicle brakes are set.
8. Remove the two bolts (1) that hold each drive
wheel disconnect plate (2).
9. Turn each disconnect plate (2) over so that
the nipple (3) points inward, then retighten
the bolts (1).
10. At the end of the tow, before you disconnect
the AB50J from the towing vehicle, turn the
disconnect plates back over so the nipples
are out. This will prevent the AB50J from
rolling when you disconnect it from the tow
vehicle.
11. Reverse the above procedure at the end of
the tow.
■ 4-Wheel Functions
❑ 4-Wheel Drive
4-wheel drive improves traction on all surfaces.
There are two ways to tell if the AB50J has
4-wheel drive.
1. Look for the “4x4” decal shown on the front of
the turntable.
2. Look at the wheels. If the hubs of all four
wheels look like this, the AB50J has 4-wheel
drive.
❑ 4-Wheel Steer
For a complete discussion of 4-wheel steer see the
4-Wheel Steer section of “Operation” chapter 8.
❑ 4-Wheel Steer With Crab Steer
For the AB50J to have crab steer it must first
have 4-wheel steer.
For a complete discussion of crab steering see
the 4-Wheel Steer with Crab Steer section of
“Operation” chapter 8.
AB50J – 0163189 page 11 - 5
11. Options
CAUTION
