The rest of this chapter shows how to perform the
inspection and maintenance required for each item
in the Daily Inspection and Maintenance Table.

■

Engine Fuel Level

Visually check to see that the gasoline or diesel
tank is full.

See the “Specifications” chapter 3, fuel for octane
and grade.

(Option - LPG) Visually check to see that the
LPG tank is full (1).

To replace an LPG tank:

1. Close the valve (2) by screwing clockwise.

2. Manually disconnect the fuel hose at the

knurled ring (3).

3. Open the strap (4).

4. Manually lift the tank out.

■

Fuel Tank Cap

Check to see that the tank cap is in place and is
tight.

■

Engine Oil Level

❑

Gasoline Engine

page 7 - 2

AB50J – 0163189

7. Daily Inspection and Maintenance
