Snorkel AB50JRT - Manual (Page 75)

8. For machines equipped with optional LPG
fuel, close the valve on the LPG tank
(completely turned clockwise).
Transporting a loose AB50J can cause Death
or Serious Injury.
DO NOT attach tie downs to the steering tie
rods. The tie rods are not strong enough to
safely hold an AB50J.
9. Attach chains to the front lifting tie down lugs
(7) on the AB50J chassis.
10. Attach chains to the rear lifting tie down lugs
(8) on the AB50J chassis.
Chocks may be removed at this time, though it
is a good idea to leave them in place.
11. Lock the cowling doors closed.
12. Use wire ties, as shown, to keep the platform
gravity gate from bouncing around.
13. Use wire ties, as shown, to keep the platform
foot switch from bouncing around.
Reverse the above procedure after transporting.
AB50J – 0163189 page 10 - 3
10. Stowing and Transporting
DANGER
