Page 32: Specifications
■
Nomenclature and Serial Numbers
AB50J – 0163189
page 3 - 5
3. Specifications
Rear
drive wheels
Front
steering wheels
Main boom
Serial
number
Turntable
Chassis
Platform controls
Platform
Front lifting
tie down lugs
❑
Right Side View Of Machine
Tip boom
Base boom
ATB 50 Main boom = Tip boom + Base boom
❑
Booms Identification
