6. Controls
■
Controls Description
This chapter shows the controls at the ground
control box and the platform control box, and
explains what each control does.
This chapter DOES NOT explain how to use
the controls to produce useful work.
“Operation” chapter 8, covers the proper use of
controls.
See the “Emergency Operation” chapter 9, for
correct emergency operation procedures.
See the “Options” chapter 11, for correct
operation procedures of any optional equipment.
The main operating functions of an AB50J can be
controlled from the ground control box or from the
platform control box.
AB50J – 0163189
page 6 - 1
Steer
Drive
Platform Controls Box Top
Platform Control Box Front
Ground Controls
■
Controls and Controls Decals Locations
