10. Stowing and Transporting
■ Stowing
At the end of each work day (or in preparation for
lifting or storage) a qualified operator should put
the AB50J into its stowed position then lock it.
The correct stowed position is shown here.
To bring the AB50J into the stowed position use
the controls on the ground control box or platform
control box to:
1. Fully retract the booms.
2. Fully lower the booms.
3. Center the main boom between the rear
wheels.
❑ To Lock the AB50J:
If the engine has just been under load and is
hot, let the engine idle for one minute.
1. Set the Master Key Switch to OFF then
remove the key.
2. Set the Battery switch to OFF and it.
3. For machines equipped with optional LPG
fuel, close the valve on the LPG tank
(completely turned clockwise).
4. Close and lock all doors.
■ Transporting
The user assumes all responsibility for choosing
the proper method of transportation, and the
proper selection and use of transportation and
tie-down devices, making sure the equipment
used is capable of supporting the weight of the
aerial platform and that all manufacturer’s
instructions and warnings, regulations and safety
rules of their employer, the DOT and/or any other
state or federal law are followed.
❑ Trailering
An AB50J weighs approximately 15,280 pounds
(6930 kg). Loading ramps must be able to
support that weight. Transport trailers must be
able to safely transport that weight.
DO NOT load an AB50J on grades over 25%;
or with the turntable rotated with respect to the
chassis; or on ramps with poor traction,
uneven surfaces, or steps.
To safely drive an AB50J onto a transport trailer:
1. Visually inspect the alignment of the loading
ramp (1) and the truck or trailer (2). They
should both be on the same straight line.
2. Chock (3) the wheels of the truck or trailer so
it cannot roll away form the loading ramp (1)
while the AB50J is being loaded.
3. Set the ground control box for platform
operation.
AB50J – 0163189 page 10 - 1
DANGER
