Technical data 13.
Reservoir
size
dimensions
l x w x h
0,2 [l]
574 x 97 x 141 [mm]
22.6 x 3.8 x 5.6 [in.]
0,5 [l]
362 x 97 x 141 [mm]
14.3 x 3.8 x 5.6 [in.]
0,9 [l]
574 x 97 x 141 [mm]
22.6 x 3.8 x 5.6 [in.]
1,8 [l]
574 x 97 x 141 [mm]
22.6 x 3.8 x 5.6 [in.]
3,8 [l]
590 x 190 x 141 [mm]
23.2 x 7.5 x 5.6 [in.]
13.1.2 Dimensions, weight, usable quantity and fill quantity
NOTE:
The dimensions of the hand pumps are exclusively dependent on the size of the
hydraulic fluid tank. The types of hand pumps are not outwardly distinguishable
from the outside at the pump head.
LH 2 / 1.8 - 50
Tank size max. operating
pressure in MPa
(1 MPa = 10 bar)
13.1.1 Pump labelling
Model series
NOTE:
The automatic pressure switch from low pressure to high pressure occurs at
2 MPa (= 20 bar)
Because all values are subject to tolerances, there cannot be any differences between the
data of your device and the data of the following tables!
13.1 Data of the hand pumps
