Lukas LH2 - Manual (Page 19)

19
7.5 Direct connection into the oil distributor block
1. Remove the closing screws form the ports „A1“, „A2“, „A3“ and/or „A4“ (according to the
number of tools you want to connect).
2. Screw the appropriate hose line / coupling directly into the distributor block and tighten
it with a torque of 45 Nm.
port “B”
supply hose
sealing ring
connecting thread
hand pump
NOTE:
The port “M” is provided for a pressure gauge, which will be tighten there with
a torque of 45Nm.
