Lukas LH2 - Manual (Page 31)

31
ATTENTION!
Properly dispose of the removed
hydraulic fluid and all damaged com-
ponents!
9.1
9.2
11.5.4 Removing tank for cleaning, replacing the tank or the seals
The tank should be cleaned at least once per year in order to remove the accumulated dirt.
The tank must be replaced if there is any external damage that impairs the safety of
the device.
The tank seals must be replaced if there are any leaks at the junction points of the tank.
Procedure:
1. Emptying the reservoir by demounting the
plug screw (Pos. 9.1) and the sealing ring
(Pos. 9.2) below and after that emptying
the reservoir.
2. Demount nut (Pos. 16.1) and sealing ring (Pos. 15.2) below.
3. Remove base plate and sealing (Pos. 15.1).
4. Remove reservoir and sealing (Pos. 15.1).
16.1 15.2
base plate
15.1
reservoir
15.1
