Infinity Supported Application 13
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware
Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest.
Pin
2G
DSM
Hardware Specification Notes
C1-59 Injector 3 Injector 3 2
Saturated or peak and hold, 3A max
continuous
Injector 3
C1-60 Power Ground Ground 26 Power Ground Connect directly to battery ground.
C1-61 +12V +12V In 25 12 v olt power f rom relay
12 v olt power f rom relay . Relay must be
controlled by +12V Relay Control signal, pin
C1-29 abov e.
C1-62 Injector 2 Injector 2 14
Saturated or peak and hold, 3A max
continuous
Injector 2
C1-63 Injector 1 Injector 1 1
Saturated or peak and hold, 3A max
continuous
Injector 1
C1-64 +12V +12V In 12 12 v olt power f rom relay
12 v olt power f rom relay . Relay must be
controlled by +12V Relay Control signal pin
C1-29 abov e.
C1-65 +12V_SW Ignition Switch 82 10K pulldown
Full time battery power must be av ailable at
C1-10 bef ore this input is triggered.
C1-66 Analog_In_Temp_1
Coolant Temp
Sensor
83 12 bit A/D, 2.49K pullup to 5V
See "Coolant Temperature" Setup Wizard f or
selection.
C1-67 Analog_In_Temp_2
Intake Air
Temperature
72 12 bit A/D, 2.49K pullup to 5V
See "Air Temperature" Setup Wizard f or
selection.
C1-68
Harness_Analog_In
_Temp_3
Oil
Temperature
Sensor
12 bit A/D, 2.49K pullup to 5V
See 1D table OilTempCal table f or calibration
data and OilTemp [C] f or channel data.
C1-69 Stepper_2A Stepper 2A 5
Automotiv e, Programmable Stepper
Driv er, up to 28V and ±1.4A
Be sure that each internal coil of the stepper
motor is properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only .
C1-70 Stepper_1A Stepper 1A 4
Automotiv e, Programmable Stepper
Driv er, up to 28V and ±1.4A
Be sure that each internal coil of the stepper
motor is properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only .
C1-71 Stepper_2B Stepper 2B 18
Automotiv e, Programmable Stepper
Driv er, up to 28V and ±1.4A
Be sure that each internal coil of the stepper
motor is properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only .
C1-72 Stepper_1B Stepper 1B 17
Automotiv e, Programmable Stepper
Driv er, up to 28V and ±1.4A
Be sure that each internal coil of the stepper
motor is properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only .
C1-73 Power Ground Ground Power Ground Connect directly to battery ground.
