AEM Infinity Supported Applications - Mitsubishi 1995-1999 4G63 Engine - Manual (Page 11)

Infinity Supported Application 11
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware
Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest.
Pin
2G
DSM
Hardware Specification Notes
C1-36 Analog_In_8 MAP Sensor 73 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins as
power supply and Sensor Ground pins as the
low ref erence. Do not connect signals
ref erenced to +12V as this can permanently
damage the ECU. See the Setup Wizard Set
Manif old Pressure page f or setup and
calibration. Monitor the MAP [kPa] channel.
C1-37 Analog_In_9 Fuel Pressure 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins as
power supply and Sensor Ground pins as the
low ref erence. Do not connect signals
ref erenced to +12V as this can permanently
damage the ECU. See the Setup Wizard Fuel
Pressure page f or setup and calibration.
Monitor the FuelPressure [psig] channel.
C1-38 Analog_In_10 Baro Sensor 85 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins as
power supply and Sensor Ground pins as the
low ref erence. Do not connect signals
ref erenced to +12V as this can permanently
damage the ECU. See the Setup Wizard
Barometric Pressure page f or setup and
calibration. Monitor the BaroPress [kPa]
channel.
C1-39 Analog_In_11
Shif t Switch
Input
12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins as
power supply and Sensor Ground pins as the
low ref erence. Do not connect signals
ref erenced to +12V as this can permanently
damage the ECU.
See the 1D lookup table 'Shif tSwitch' f or
setup. Also assignable to multiple f unctions.
See Setup Wizard f or details.
C1-40 Analog_In_12 Mode Switch 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins as
power supply and Sensor Ground pins as the
low ref erence. Do not connect signals
ref erenced to +12V as this can permanently
damage the ECU.
See the 1D lookup table 'ModeSwitch' f or input
state.
A multi-position rotary switch such as AEM P/
N 30-2056 is recommended.
Also assignable to multiple f unctions. See
Setup Wizard f or details.
C1-41 +5V_Out_1 +5V Out 81
Regulated, f used +5V supply f or
sensor power
Analog sensor power
C1-42 +5V_Out_1 +5V Out
Regulated, f used +5V supply f or
sensor power
Analog sensor power
C1-43 HighsideSwitch_1
HS1 (switched
12V)
0.7A max, High Side Solid State
Relay
See Setup Wizard page 'HighSide Assigment
Tables' f or conf iguration options.
See 2D lookup table 'HS1_Table' f or
activ ation settings.
