AEM 30-6600 Series 2 Plug & Play EMS User Manual
Page 11
30-1600 (Series 1) vs 30-6600 (Series 2) EMS differences:
The EMS functions assigned to certain pins have been changed and no longer
match the 30-1600 EMS. Unless otherwise noted, the following pins and functions
will need to be manually reconfigured after using AEMTuner to convert a V1.19 30-
1600, Series 1 EMS calibration for use with the 30-6600 Series 2 hardware.
Pin
Vehicle harness
destination
30-1600 function
30-6600 function
Notes
12
CAN
Low Side 8
CAN1H
LS8 not available
15
TX Data
Injector 8
EGT 2
Injector 8 moved to pin 114
42
CAN
Switch 1
CAN1L
Switch 1 not available
114
---
EGT 2
Injector 8
EGT 2 moved to pin 15
Page 11 of 12
