OVERVIEW
The 30-3508 AEM Infinity Adapter Kit is designed for the 2000
–
2005 Honda S2000. These models include
all 2.0L (AP1) engines as well as the early 2.2L (AP2) engines with a cable driven throttle body. This is a
true standalone system that eliminates the use of the factory ECU. The use of this adapter makes the kit
“plug and play” so no cutting or splicing wires is necessary. The base configuration files available for the
Infinity EMS are starting points only and will need to be modified for every specific application.
The available AEM Infinity EMS part numbers for this adapter kit are:
30-7106 INFINITY-6
30-7108 INFINITY-8h
GETTING STARTED
Refer to the 10-7100 for EMS 30-7100 Infinity Quick Start Guide for additional information on getting
the engine started with the Infinity EMS. Base sessions are located in C:\Documents\AEM\Infinity Tuner
\Sessions\Base Sessions
DOWNLOADABLE FILES
Files can be downloaded from
. An experienced tuner must be available to configure
and manipulate the data before driving can commence. The Quick Start Guide and Full Manual describe
the steps for logging in and registering at
These documents are available for
download in the Support section of the AEM Electronics website:
Downloadable files for 2000
–
2005 Honda S2000
7106-XXXX-75 Infinity-6 (XXXX = serial number)
7108-XXXX-76 Infinity-8h (XXXX = serial number)
OPTIONS
30-2001 UEGO Wideband O2 Sensor
Bosch LSU4.2 Wideband O2 Sensor that connects to AEM 30-3600 UEGO Wideband O2 Sensor
Extension Harness
30-3600 UEGO Wideband O2 Sensor Extension Harness
Extension harness to connect AEM UEGO Wideband O2 sensor to 6-pin Deutsch
30-3602 IP67 Logging Cable
USB A-to-A extension cable: 39” long with right angled connector and bayonet style lock
