AEM 30-3508 Infinity Plug & Play Harnesses - Honda 2000-2005 S2000 User Manual
Page 12
12
© 2014 AEM Performance Electronics
P/N 30-3508
Infinity
Pin
Infinity
Assignment
Honda Pin
Honda Description
Infinity Hardware
Specification
Notes
52
Ana8 - Map
C17
MAP Sensor
12 bit A/D, 100K pullup to
5V
0–5V analog signal. See the Manif old
Pressure in Setup Wizard f or setup and
calibration.
53
Ana9 - Fuel
Press
---
---
12 bit A/D, 100K pullup to
5V
0–5V analog signal f ound on the Auxiliary
Connector
54
VR2 (+) -
Driv en
Wheel
---
---
Dif f erential Variable
Reluctance Zero Cross
Detection
See Driv en Wheel Speed Calibration in the
Setup Wizard Vehicle Speed page.
55
VR2 (-) -
Driv en
Wheel
---
---
Dif f erential Variable
Reluctance Zero Cross
Detection
See Driv en Wheel Speed Calibration in the
Setup Wizard Vehicle Speed page.
56
VR3 (-) - Tag
Wheel
---
---
Dif f erential Variable
Reluctance Zero Cross
Detection
See Non Driv en Wheel Speed Calibration in
the Setup Wizard Vehicle Speed page.
57
VR3 (+) - Tag
Wheel
---
---
Dif f erential Variable
Reluctance Zero Cross
Detection
See Non Driv en Wheel Speed Calibration in
the Setup Wizard Vehicle Speed page.
58
HS Out 0
B12
VTEC solenoid Valv e
0.7A max, High Side Solid
State Relay
+12V High Side Driv e. See Setup Wizard
Honda VTEC page f or options.
59
Stepper_1B
---
---
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of the stepper
motor is properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only .
60
Stepper_2B
---
---
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of the stepper
motor is properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only .
61
HBridge0_0
---
---
5.0A max Throttle Control
Hbridge Driv e
2000–2005 S2000 do not use driv e by wire
throttle.
62
HBridge0_1
---
---
5.0A max Throttle Control
Hbridge Driv e
2000–2005 S2000 do not use driv e by wire
throttle.
63
+12V
---
---
Main Power
12 v olt power f rom relay powers the Inf inity ,
Lambda sensor, and AEMNet
64
Injector 6 -
Peak & Hold
---
---
Saturated or peak and hold,
3A max continuous
Spare injector output
65
Injector 5 -
Peak & Hold
---
---
Saturated or peak and hold,
3A max continuous
Spare injector output
66
Injector 4 -
Peak & Hold
B5
Injector 4
Saturated or peak and hold,
3A max continuous
Injector 4
67
GND
B22
Logic Ground 2
Power Ground
Connects directly to ground
68
+12V
---
---
Main Power
12 v olt power f rom relay powers the Inf inity
69
Ana19 -
APP2
---
---
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Do not connect signals
ref erenced to +12V as this can permanently
damage the ECU.
70
Ana18 -
APP1
---
---
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Do not connect signals
ref erenced to +12V as this can permanently
damage the ECU.
71
Ana16
- Throttle2
---
---
12 bit A/D, 100K pullup to
5V
0–5V analog signal f ound on the Auxiliary
Connector
