10-2860 B Series COP Instructions RevB 111117
SPECIFICATIONS
30-2860 B Series COP
Ignition Type
Inductive with Igniter
Ignition Channels
4
Timing Pattern
24 Crank, 1 Cam
Timing Pattern Signal
12 volt square wave
Ignition Trigger Signal
5 volt logic level falling edge trigger
Boost Level
Up to 15 psi
Max Dwell Time
See Table 1
Operating Voltage (nominal) 12 volts dc
RECOMMENDED PARTS
30-51XX
Analog Style Gauges
30-44XX
Digital Style Gauges
30-2340
4 Channel UEGO Controller
30-4100
Digital Gauge Style UEGO Controller
30-5130
Analog Gauge Style UEGO Controller
30-2310
Inline UEGO Controller
30-2500
AQ1 Data Logger
30-2821
4 Channel Twin Fire CDI (Optional upgrade for higher boost levels above
15 psi, some wiring required)
REPLACEMENT PARTS
30-2840
4 Channel Igniter
30-3255
Honda EPM
30-2850
Coil
35-3860
B Series COP Harness
35-3861
EPM Harness
