Tuning Guide 35
© 2014 AEM Performance Electronics
NOTE: If the Setup Wizard does not contain your specific fuel injector type, you can modify the
InjFlowRate table manually. If you do not know the different flow rates at different fuel pressures,
choose a flow rate (based on Manufacturers specs) at a known pressure and populate the entire
row with that value. For example, you have a fuel injector that is not listed in the Wizard Selection.
You know that it flows 475 cc/min at 45 psi. Select the cells in the upper row of the InjFlowRate
[cc/min] table and manually input 475. This will suffice to get the car up and running, though
proper flow data is ideal.
Set Throttle Range
The wizard displays a warning message to the user if the software is not connected to a
hardware target.
Live TPS Volts
Text and graphical representation of the raw analog voltage is shown.
