Tuning Guide

process notifying the user of each step along the way. If the import function is done while
connected to an ECU, after the import is complete:

1) Turn the key off and wait for the main relay to power down completely. This usually takes

about 10 seconds but depends on the model.

2) Turn the key back on.

Certain applications with CAN dash requirements must be powered down completely and

restarted after an import calibration. If this is not done, error lights may appear on the dash.

Please be aware of cross-platform differences that may require additional attention after
importing calibration data. For instance, the Digital7 pin is available on the Infinity-6 ECU but not
available on the Infinity-8H ECU. After importing Infinity-6 session data to an Infinity-8, any input
that was assigned to use Digital7 will be displayed as invalid in the wizard and needs to be
reassigned to work properly.
